R1 Pine Green
Crafted in collaboration with Nordoff and Robbins
R1 Pine Green
Crafted in collaboration with Nordoff and Robbins
Representing a new look for the beloved radio, R1 MK4’s beautifully finished Pine Green exterior and handcrafted wooden grille bring the outside in, whether its soundtracking cosy winter nights by the fire or providing the ambience for a hazy summer afternoon.
A donation to Nordoff and Robbins will be made for every one of these limited-edition radios sold.
About Nordoff and Robbins
Nordoff and Robbins, the UK’s largest music therapy charity, has over 60 years of practice in using music to break barriers caused by illness, disability, and social isolation. It provides therapy across the UK, trains future therapists, and funds research to enhance its impact. The charity helps individuals, including those with autism, dementia, learning difficulties, brain injuries, and mental health issues, to connect and communicate through music. With specialist centers in several cities and sessions in schools, hospitals, and care homes, its training is validated by Goldsmiths, University of London, and approved by the HCPC. Nordoff and Robbins believes in transforming lives through music therapy.
Specifications
Audio
- Frequency response (typical in-room)
- 55Hz - 20kHz
- Speaker unit
- Ruark 75mm NS+ full range driver
- Amplifier
- 9W nominal Class AB
- Enhancements
-
Adjustable bass and treble (-8dB to +8dB),
Switchable loudness EQ - Cabinet type
- Bass reflex
Connectivity
- Aerial connector
- 75Ω F-type connector
- Bluetooth (version & codecs)
- V4.2, SBC, AAC
- Headphone output
- 3.5mm jack socket
- Line in
- Stereo 3.5mm jack input
- Radio
- DAB/DAB+, FM with RDS (Multi region 76.0-108MHz)
- USB-C port
- 5V 1A (5W) charging and MP3 shuffle playback
- Supported audio formats
- MP3 up to 48kHz 320 kbps,
AAC up to 96kHz 320kbps
Features
- Adjustable input levels
- Line in
- Alarms
- 2 × daily, weekdays, weekends and custom
- Auto standby
- Adjustable power saving mode
- Daylight Saving Time (DST)
- Configurable daylight savings
- Display
- High-contrast OLED with auto dimming
- Presets
- 8 presets per mode
- Real-Time Clock (RTC)
- With internal battery backup
- Remote control
- Optional compact IR remote
- Security slot
- Kensington compatible
- Sleep function
- Yes
- Snooze function
- Yes
- Software updates
- USB
- User interface languages
- EN, DA, DE, ES, FR, IT, JP, KO, NL, NO, PL, RU, SV, ZH
General specifications
- Finish
- Pine Green lacquer cabinet with Ash grille
- Product dimensions (cabinet)
- H170 × W130 × D130mm
- Product dimensions (max – inc. feet, controls and cables etc.)
- H185 × W130 × D160mm
- Product weight
- 1.4kg
- Product power input
- 12-14VDC 1.5A
- Power inlet connector
- 5.5 × 2.1mm DC jack socket
- AC power adaptor
- 100-240VAC, 50-60Hz input, 14VDC 1.5A output (1.8m lead)
- Power consumption
- 0.7W standby 3W typical
In the box
- R1 Mk4
- Universal AC power adaptor
- Quick Start Guide
- Telescopic aerial
Carton
- Carton dimensions
- H270 × W185 × D210mm
- Packaged weight
- 2.1kg
